| ENGINE | Type | Horizontal water cooled 4 cycle diesel engine | |
| Model | KUBOTA RT 140DI | ||
| No. of Cylinders | 1 | ||
| Bore x Stroke (mm) | 97 x 96 | ||
| Displacement (cc) | 709 | ||
| Maximum Output (HP/rpm) | 14.0/2400 | ||
| Continuous Rated Output (HP/rpm) | 12.5/2400 | ||
| Lubricating Oil | SAE # 40 API CF | ||
| Cooling System | Radiator | ||
| Fuel | Light Diesel Oil (SAE # 2-D) | ||
| Fuel Tank Capacity (L) | 11 | ||
| GENERATOR | Type | Brushless | |
| Model | MECC ALTE S20 FS-130/A | ||
| Max. Output (kVA) | 7.5 | ||
| Rated Output (kVA) | 7 | ||
| Revolutions per minute (rpm) | 3000 | ||
| Frequency (Hz) | 50 | ||
| No. of Pole | 2 | ||
| Power Factor | 1 | ||
| Phase | 1 Phase 2 Wire | ||
| Voltage (AC) | 220 | ||
| Insulation | Class H | ||
| DIMENSION AND WEIGHT | Width (mm) | 597 | |
| Length (mm) | 1283 | ||
| Height (mm) | 703 | ||
| Net weight (Dry) (Kg) | 275 | ||
| GENERATOR CAPACITY (FOR HOME USED) | Air Conditioner | 12,000BTU (4800W) | |
| Small Refrigerator | 90W | ||
| Television 29″ | 145W | ||
| Electric Fet | 750W | ||
| Fan 16″ | 80W | ||
| Stereo | 75W | ||
| Light (Home Use) | 36W | ||
| Computer & Printer | 850W | ||
